G3‐Gateway‐EPM
The Solis G3-Gateway-EPM is a datalogger with export power management (EPM) control, with 8 RS485 ports (up to 15 inverters each), 2 LAN ports, Modbus-TCP and IEC 60870-5-104 support, 5-minute data collection and rail or desktop mounting.
Technical Specifications
| Models | G3-Gateway-EPM |
| Communication | |
| Supported device type | Solis inverter |
| Number of connected inverters | Each RS485 PORT≤15 |
| Data collection intervals | 5 minutes |
| RS485 | COM × 8, 1200~19200 bps, communication distance ≤1000 m |
| Ethernet communication | LAN × 2, 10/100 Mbps adaptive, communication distance ≤100 m |
| RS485 | Modbus-RTU, IEC60870-5-103, DLT645 |
| Ethernet | Modbus-TCP, IEC60870-5-104 |
| Electrical | |
| AC power supply | 100~240 V, 50 Hz / 60 Hz |
| DC power supply | 9~36 V |
| Operating power consumption | 5 W@12VDC |
| Environment | |
| Operating temperature | -40 ~ +80°C |
| Storage temperature | -40 ~ +80°C |
| Operating humidity | ≤85%, Relative humidity, no condensa |
| Max. operation altitude | 4000 m |
| Dimensions (L*W*H) | 121*54*200 mm |
| Protection degree | IP20 |
| Installation method | Rail Mounting, Desktop installation |
| Others | |
| Certification | CE, RoHS |
